Warehouse Equipment Solutions
specializes in custom designing storage systems
for our customer's application needs and budget with regard to product flow and material handling equipment. Our designs are targeted to maximize storage and increase your warehouse organization and business efficiency. The staff of Warehouse Equipment Solutions has some of the most creative minds in the pallet rack industry. From simple selective pallet rack to complicated Pick Modules and engineered systems projects, we can provide CAD approval drawings, permitting drawings and ensure that your warehouse storage project will increase efficiency. We use the latest in Computer Aided Design (CAD) to plan and design your warehouse storage system. Whether we are implementing full warehouse pallet racking and picking systems or a small scale shelving project, CAD software ensures that the project is designed with your budget, facility measurements, project requirements in mind, layouts include racking, shelving, building structures, trucks, etc., enabling you to see, review and, if necessary, revise exactly your final design. This advance review pinpoints potential problems before they occur, saving you both time and money. CAD drawings can be plotted and mailed to you or sent via email. Our team can help design your facility including:
Warehouse Equipment Solutions can prepare a layout and provides preliminary floor plans using information provided by the salesperson or customer. Consult with customer and sales to determine functional and spatial requirements of the warehouse, in order to maximize use of warehouse space. Apply knowledge of design, construction procedures, zoning and building codes, and building characteristics. Review customer profile and permit information to determine critical details of the project. Prepare scaled AutoCAD drawings and documents of a project and integrate engineering elements into a unified design. Contact the customers other contractors to provide plans for quoting proposes and review the scope of the projects with emphases on the expected time of completion.
We create final plan drawings in accordance with local and uniform construction code requirements for township permit approval. Send the floor plans and detailed descriptions of the warehouse racking or other structures to an independent Professional Engineer for seismic certification along with sealed floor plans for egress and other requirements, according to building codes.
We generate and submit all required documents for township, property owners and any other governing parties. Review plans with township officials for approval. Review material requirements and any expectable alternative materials with shop manager. Resolve any problems that occurred during project, such as field adjustments, use of alternate materials, permit issues.
Here are just a few examples of CAD drawings we have done for our customers.
